State Machines in iOS: Turning “Navigation” Into a Testable Process

Aylwing Olivas

21 Jan 2026 — 7 min read

Most apps don’t have a navigation problem. They have a process problem.

“Which screen comes next?” is usually a side-effect of something deeper:

Did we hydrate from disk?
Are we authenticated?
Is the network reachable?
Did we complete onboarding?
Did we satisfy required permissions?
Did the backend acknowledge the last sync batch?

When that logic is scattered across view models, coordinators, and callbacks, you get the classic failure mode: the app usually works—until it doesn’t—and reproducing the bug becomes archaeology.

A state machine is the simplest way I know to make the process explicit, deterministic, and testable.

If you already use coordinators (UIKit or SwiftUI routing), a state machine typically sits one level above them:

State machine: decides which flow is active and what transitions are allowed
Coordinator/Router: executes navigation for that active flow
UI: renders the current state and sends intents/events

This post shows a pragmatic pattern I use: a state machine with:

pre-transition validation (can we move?)
pre-transition hooks (do work before moving)
post-transition hooks (cleanup / side-effects)
an orchestrator that owns long-running logic and uses the machine as the source of truth

No “framework,” no ceremony—just something small that survives reality.

A quick war story (why this exists)

A common production bug looks like this:

App launches and begins hydration
A deep link arrives immediately and tries to route to a detail screen
Another async task finishes slightly later and “wins,” pushing the app back to a default screen
You get a flaky “sometimes deep links don’t work” report that’s hard to reproduce

This isn’t a UI problem. It’s a process problem: multiple async tasks are deciding “what happens next” without a single source of truth.

The goal: one source of truth for “where the app is”

I want exactly one place that can answer:

What state is the app in, and why?

This is not about replacing SwiftUI navigation. It’s about separating concerns:

State machine: the truth table for allowed transitions
Orchestrator: performs I/O and decides which events to send
UI: reacts to state, triggers user intents, stays dumb

If you mix these, you get “UI drives the process,” which becomes fragile fast.

When a state machine is worth it

I reach for a state machine when:

there are 5+ steps in a flow (onboarding, wallet creation, checkout, KYC, offline sync)
steps have async work (network + disk)
there are failure states that need clear recovery paths
you need invariants (“you can’t be Ready if auth == false”)

When I don’t use it:

a simple linear flow
single-screen forms
cases where a plain enum + straightforward branching is enough

If a state machine makes the code harder to read than the problem, don’t use it.

Design first: draw the flow (even a simple one)

Before code, I write the diagram / truth table. For a basic startup flow:

launching
  └─(didLaunch)→ hydrating
        ├─(hydrateSucceeded: false)→ needsLogin
        │       └─(loginRequested)→ authenticating
        │               ├─(loginSucceeded)→ ready
        │               └─(loginFailed)→ error
        └─(hydrateSucceeded: true)→ ready (or validate token → ready/error)
error
  └─(retry)→ hydrating

The point is not the diagram itself—it’s that the logic is explicit and centralized.

Why not just use GameplayKit’s

GKStateMachine

?

GKStateMachine is a legitimate option and the mental model is excellent:

Each state decides what’s legal next (isValidNextState)
Enter/exit lifecycle hooks exist (didEnter(from:), etc.)

Those map directly to the approach below:

isValidNextState → validator
didEnter / exit lifecycle → hooks

So why show an actor-based reducer machine instead?

Many app flows want async work and cancellation to be first-class.
I usually prefer value-typed state + event, with a truth-table reducer that’s trivial to test.
I want the orchestration story to be explicit: the state machine stays deterministic; I/O happens elsewhere.

If you prefer GameplayKit, you can still apply the same architecture: keep states shallow, centralize side-effects, and test transitions like a truth table.

A concrete example: app startup → authenticated → ready

Let’s model a simplified startup flow:

Launch
Hydrate local session
Ready (authenticated) or NeedsLogin
Error (with retry)

State and event

enum AppState: Equatable {
    case launching
    case hydrating
    case needsLogin
    case authenticating
    case ready(userID: String)
    case error(message: String)
}

enum AppEvent: Equatable {
    case didLaunch
    case hydrateSucceeded(hasSession: Bool)
    case loginRequested
    case loginSucceeded(userID: String)
    case loginFailed(message: String)
    case retry
}

Rules that keep this sane

This is the part that prevents state machines from becoming magical:

Validators are pure. No I/O. No async. No side-effects.If you can’t unit test a validator without mocks, it’s not a validator.
Hooks are boring. Logging, metrics, cancellation, teardown—cross-cutting concerns.
Orchestrators own I/O. Network/disk belongs outside the state machine.

Adding validators + hooks (pre and post)

Protocol surface

protocol TransitionValidator {
    associatedtype State
    associatedtype Event
    func canTransition(from: State, event: Event, to: State) -> Bool
}

protocol TransitionHook {
    associatedtype State
    associatedtype Event
    func willTransition(from: State, event: Event, to: State) async throws
    func didTransition(from: State, event: Event, to: State) async
}

A minimal state machine implementation (Swift concurrency)

This implementation is intentionally small:

it serializes events (avoids reentrancy bugs)
it checks validation before moving
it runs pre/post hooks
it makes illegal transitions observable

import Foundation

enum TransitionError: Error {
    case invalidTransition
    case preHookFailed
}

actor StateMachine<State: Equatable, Event> {

    typealias Reducer = (State, Event) -> State?
    private var state: State
    private let reducer: Reducer

    private let validators: [any TransitionValidatorBox<State, Event>]
    private let hooks: [any TransitionHookBox<State, Event>]

    /// Policy: most apps should *ignore* unknown events (but log them).
    /// Throwing is useful when a violation indicates a programming error.
    private let throwsOnInvalid: Bool

    init(
        initial: State,
        reducer: @escaping Reducer,
        validators: [any TransitionValidatorBox<State, Event>] = [],
        hooks: [any TransitionHookBox<State, Event>] = [],
        throwsOnInvalid: Bool = false
    ) {
        self.state = initial
        self.reducer = reducer
        self.validators = validators
        self.hooks = hooks
        self.throwsOnInvalid = throwsOnInvalid
    }

    func currentState() -> State { state }

    func send(_ event: Event) async throws -> State {
        guard let next = reducer(state, event) else {
            if throwsOnInvalid { throw TransitionError.invalidTransition }
            return state
        }

        for v in validators {
            guard v.canTransition(from: state, event: event, to: next) else {
                if throwsOnInvalid { throw TransitionError.invalidTransition }
                return state
            }
        }

        for h in hooks {
            do { try await h.willTransition(from: state, event: event, to: next) }
            catch {
                if throwsOnInvalid { throw TransitionError.preHookFailed }
                return state
            }
        }

        let previous = state
        state = next

        for h in hooks {
            await h.didTransition(from: previous, event: event, to: next)
        }

        return state
    }
}

Swift doesn’t allow any ProtocolWithAssociatedType directly in arrays without type erasure, so here are small “boxes”:

protocol TransitionValidatorBox<State, Event> {
    func canTransition(from: State, event: Event, to: State) -> Bool
}

struct AnyTransitionValidator<State, Event>: TransitionValidatorBox {
    private let _can: (State, Event, State) -> Bool
    init(_ can: @escaping (State, Event, State) -> Bool) { self._can = can }
    func canTransition(from: State, event: Event, to: State) -> Bool {
        _can(from, event, to)
    }
}

protocol TransitionHookBox<State, Event> {
    func willTransition(from: State, event: Event, to: State) async throws
    func didTransition(from: State, event: Event, to: State) async
}

struct AnyTransitionHook<State, Event>: TransitionHookBox {
    private let _will: (State, Event, State) async throws -> Void
    private let _did: (State, Event, State) async -> Void

    init(
        will: @escaping (State, Event, State) async throws -> Void = { _,_,_ in },
        did: @escaping (State, Event, State) async -> Void = { _,_,_ in }
    ) {
        self._will = will
        self._did = did
    }

    func willTransition(from: State, event: Event, to: State) async throws { try await _will(from, event, to) }
    func didTransition(from: State, event: Event, to: State) async { await _did(from, event, to) }
}

Reducer for the startup flow (the truth table)

let reducer: (AppState, AppEvent) -> AppState? = { state, event in
    switch (state, event) {
    case (.launching, .didLaunch):
        return .hydrating

    case (.hydrating, .hydrateSucceeded(let hasSession)):
        return hasSession ? .ready(userID: "unknown-yet") : .needsLogin

    case (.needsLogin, .loginRequested):
        return .authenticating

    case (.authenticating, .loginSucceeded(let userID)):
        return .ready(userID: userID)

    case (.authenticating, .loginFailed(let message)):
        return .error(message: message)

    case (.error, .retry):
        return .hydrating

    default:
        return nil
    }
}

Where the orchestrator fits (and why it matters)

A state machine defines what can happen. The orchestrator defines what should happen and when.

Example: on app launch, the orchestrator triggers hydration, then sends events based on results.

final class AppOrchestrator {
    private let machine: StateMachine<AppState, AppEvent>

    init(machine: StateMachine<AppState, AppEvent>) {
        self.machine = machine
    }

    func start() {
        Task {
        do {
            _ = try await machine.send(.didLaunch)
            let hasSession = await loadSessionFromDisk()
            _ = try await machine.send(.hydrateSucceeded(hasSession: hasSession))
        } catch {
            // Handle startup failure
            print("Startup failed: \(error)")
        }
    }
    }

    private func loadSessionFromDisk() async -> Bool {
        try? await Task.sleep(nanoseconds: 150_000_000)
        return false
    }
}

This keeps UI simple:

UI reads state and renders the screen for that state
UI sends intents (“loginRequested”)
orchestrator does I/O and sends results (“loginSucceeded”)

If you use coordinators, this is also where you decide which coordinator is active, and you keep dependencies centralized (router/presenter, storage/session, etc.).

Why pre/post hooks are useful (without abusing them)

I use hooks for cross-cutting concerns that should not be scattered:

logging, analytics, metrics
timing (“time spent in state X”)
cancellation and teardown on exit (stop tasks, release child coordinators)
starting/stopping background loops (like periodic sync)

Example hook: log transitions.

let loggingHook = AnyTransitionHook<AppState, AppEvent>(
    will: { from, event, to in
        // log("will: \(from) --\(event)--> \(to)")
    },
    did: { from, event, to in
        // log("did: \(from) --\(event)--> \(to)")
    }
)

What I avoid: putting business logic into hooks. Hooks should be shallow and boring.

Testing: the real reason this pattern pays off

This is why it’s senior: you can unit test the process like a truth table.

Given state X and event Y, assert next state Z
Assert illegal transitions are ignored (or throw)
Assert validators block transitions
Assert orchestrator emits events in order (with test fakes)

Even if the UI changes, your process remains stable.

Startup-scale vs big-org scale (what changes)

The pattern stays the same; the constraints change.

In a startup / small team, I keep it lean:

fewer states, fewer abstractions
ignore invalid transitions + log (don’t crash users)
focus on a handful of tests that catch races and regressions

In a larger org / regulated environment, I get stricter:

stronger invariants, more exhaustive transition coverage
tighter observability (transition auditing, metrics)
clearer separation of responsibilities across modules

Same model—different rigor, based on risk and change velocity.

The takeaway

If your flow is more than a couple steps and has async work, treat it like a process:

put the truth table in one place (state machine / reducer)
put side-effects in one place (orchestrator)
keep UI reactive, not “in charge”

You’ll ship fewer “impossible” bugs and you’ll spend less time debugging invisible coupling across screens.
